Simplecom SD550v2 USB 3.2 Gen2x2 to Dual Bay NVMe M.2 SSD Docking Station Duplicator

SD550v2 is a dual-bay NVMe M.2 SSD docking station designed to access two NVMe M.2 SSDs simultaneously. This allows for effortless file transfer or backup operations between two NVMe M.2 SSDs. With multi-LUN (logical unit number) support, it displays two separate drive letters, simplifying the process of copying files between drives. Fast USB 3.2 Gen2x2 interface support up to 20Gbps data transfer rate and can be easily attached to computer USB port. Two M.2 slots are protected by a sliding cover when not in use, preventing dust from entering.

When not connected to a computer via USB, it can function as a standalone duplicator dock. This feature enables effortless duplication of NVMe M.2 SSDs without the need for a computer host, making it perfect for tasks like data backup and migration. It offers a simple and efficient solution for tasks such as data backup, batch processing data, formatting, file transfers, data recovery, and more.

Features

Dual Bay NVMe M.2 SSD docking station, supports two NVMe M.2 SSDs

Access data from two NVMe M.2 slots simultaneously

Support multi-LUN (logical unit number), each slot has a separate drive letter

USB 3.2 Gen2x2 interface support up to 20Gbps data transfer rate

Support offline clone, standalone duplicating cloning without host computer

Sliding cover to protect two M.2 slots when they are not in use

Compact design, save and tidy your desktop space

LED light indicates power and activity status

Specifications

Model: SD550v2

Interface: USB-C (USB 3.2 Gen2x2)

Transfer Rate: up to 20Gbps

SSD Support: NVMe M.2 Only

SSD Size Support: 2230, 2242, 2260, 2280, 22110

Multi-LUN Support: Yes

DC Input: 12V2A

Net Weight: 88g

Dimensions: 72 x 72 x 22mm

Operating System Support: Windows 7 and above, Mac OS 10.8 and above

Package Contents

1x SD550v2 Docking Station

1x USB-C to USB-C Cable

1x Power Adapter

1x User Manual
